Mini MAU Page 9
Thin cable (10Base2) with Mini
MAU
Connect the 10Base2 Mini
MAU to the device’s AUI port.
Before the 10Base2 Mini MAU
is connected to the thin Ether-
net cable, there may be a
straight-through (barrel) BNC
connector in the cable at the
location where a node connec-
tion is available.
Simply remove the barrel con-
nector, and
c onnect a “T” con-
nector to the BNC port on the
Mini MAU. The connector
slips on, twists, and locks in
place.
❖ Note: Check with your network adminis-
trator before disconnecting cable. Other
users must be warned of the interruption
of network operations. Even if the network
uses self-terminating media or connectors,
users downstream from the break will be
affected.
❖
