Installation Mini MAU
The installation of an Asanté Mini MAU is
very simple:
1
Locate the AUI port on the
device.
The AUI is on the rear of your
hub or computer. Externally it
consists of the 15 pin AUI con-
nector.
2
Connect the Mini MAU to the
AUI port.
3
Connect the Ethernet cable to
the Mini MAU.
Twisted-pair cable (10BaseT) with
Mini MAU
Connect the 10BaseT Mini
MAU to the device’s AUI port.
Plug one end of the cable into
the 10BaseT port on the Mini
MAU.
