Mini MAU

Page

16

Mini 10BaseFL MAU

LED

Color

Status

Power on

Green

MAU ON

receiving power
from AUI

Link

Green

ON Link OK

OFF Link failed

Receive

Green

ON

MAU is receiving

Transmit

Green

ON

MAU is transmitting

Jabber

Yellow

ON

Transceiver stops
transmitting due to
a packet transmis-
sion exceeding
more than 20 ms.

Collision

Yellow

ON

Collision on Net-
work

minimau Page 16 Monday, August 26, 1996 11:02 AM
