Mini MAU Page 13
Switches for 10BaseT MAU
There are three switches on the side on the
10BaseT Mini MAU.The default settings for
the switches are identified below.
❏ Heartbeat Enable (HBE)func-
tion disabled.
(1, switch UP)
❏ Link Test (LNK) enabled
(1, switch UP)
❏ Polarity Correction (POL)
enabled
(1, switch UP)
HBE Switch
If this switch is enabled a short burst of col-
lision signal, (heartbeat) is transmitted
from MAU to the device it’s connected to
after every packet is transmitted. It is also
referred to as the SQE (Signal Quality Error
test).
By default the HBE function is disabled the
DIP switch is set to the “UP” (1) position.
