Mini MAU Page 12
LEDs and Switches for the Mini
MAU
Mini 10BaseT MAU LED Display
LED Color Status
Power on Green MAU ON
receiving power
from AUI
Link Green ON Link OK
OFF Link failed
Receive Green ON
MAU is receiving
Transmit Green ON
MAU is transmitting
Polarity Yellow ON
MAU polarity is
reversed
Collision Yellow ON
Collision on Net-
work
