Mini MAU Page 14
❖ Note: If the MAU is used with a hub
or repeater this switch should be
disabled.
❖
Link Integrity Enabled Test Switch
This switch is normally enabled to verify
cable link. This switch can be disabled to
work with non-10BaseT compliant
repeaters and hubs.
Polarity Correction
This switch, when enabled, inverts the
polarity of a signal automatically if a
received signal has reverse polarity. Wir-
ing problems cause reverse polarity.
❖ Note : If you use the MAU with an
AsantéHub leave the Polarity Cor-
rection Switch enabled.
❖
