Specifications
61182301E1-5A 9
SPECIFICATIONS
Specifications for the NTU-8F are detailed in Table 6 .
Table 6. NTU-8F Specifications
Specification Description
Environmental
Operating Temperature:
Storage Temperature:
Relative Humidity:
–5°C to +55°C
–40°C to +85°C
Up to 95% noncondensing
Physical
Dimensions:
Weight:
Height: 1.8 inches
Width: 8.0 inches
Depth: 9.0 inches
2.5 pound
Power
Input Voltage Range:
Maximum Current Draw:
Maximum Power Dissipation:
–42 VDC to –56 VDC inputs
90 mA at –48 VDC
4.32 watts
Optical
Fiber Type:
Wave length:
Optical Budget:
Transmit Level:
Receive Level:
Connector:
Single Mode
1310 nm receive and 1550 nm transmit
17 +1 dB
–14 +1 dB (worst case)
–31 +1 dB (worst case)
Single SC connector
Connectors
E1 Interface:
Fiber:
RJ-45
Flat SC adapter
Part Number
NTU-8 Single Fiber Quad E1: 1182301E1
Compliance
Agency Approval: UL 60950
