Chapter 1. Product overview
This chapter provides an overview of the tablet, including the locations of connectors and controls, tablet
features, accessories, specifications, operating environment, and preinstalled Lenovo programs.
Tablet layout
This topic introduces the tablet hardware features to give you the basic information you need to start
using the tablet.
Front view and side view
1 Microphones 2 Ambient light sensor
3 Front-facing camera 4 Screen-rotation-lock button
5 Power button 6 Combo audio connector
7 Volume-control buttons 8 Emergency-reset hole
9 NFC logo (on some models) 10 Micro-SIM-card slot
11 Micro-SD-card slot 12 Micro HDMI TM connector
13 Windows Start screen control 14 Keyboard connector
15 Dock connector 16 Multi-touch screen
17 Power connector 18 USB 2.0 connector
© Copyright Lenovo 2014 1
