Removing the power supply retaining screws – Lenovo ThinkStation S20 User Manual
Page 32
5. Remove the five screws at the rear of the chassis that secure the power supply assembly.
Figure 25. Removing the power supply retaining screws
6. Depress the power supply assembly latch
1
. Slide the power supply assembly toward the front of
the computer and remove it from the chassis.
26
ThinkStation Hardware Installation and Replacement Guide
