American Power Conversion Smart-UPS User Manual
Page 23

Configuration – Connection of Load to the PDU
990-2818A
Smart-UPS® VT ISX 20-30 kVA, 200 V Operation
17
Select transformer breaker , , or and set to the OFF position.
Set the applicable breaker on the set to the OFF position.
Connect the load plug to the receptacle (make a note of which receptacle supplies which load).
Secure the plug by turning it clockwise approximately 30°.
Set the applicable breaker set on the PDU and on the transformer to the ON position to supply the
load.
