Overview – Display Overview

10

Smart-UPS® VT ISX 20-30 kVA, 200 V Operation

990-2818A

The top line indicates date, time and event number.
Lines 2, 3 and 4 are part of the event list. To view the entire list, use UP/DOWN arrows to navigate. For
a detailed description of a particular event, position the arrow, and press ENTER.

View Statistics (submenu under Logging).

From the Logging screen on the Main Menu, you can view the statistics on operation mode changes,
inverter time, duration of battery operation.

• From the Main Menu, select Logging

• Select View Statistics

• Press ESC to return to Main Menu

Alarm threshold

If the load level exceeds the pre programmed threshold, the UPS will display a warning.
Example:

To change the Alarm Thresholds,

• Select Setup from the Main Menu

• Select Alarms from the Setup Menu

• Press ESC to return to the Main Menu

Display setup

From the Display setup screen, you can select your display Language, Contrast and Beeper functions.

24-Sep 15:06:48 #15

Mains out of

On Line

Range

===================

Logging Screen

Control

Status

Setup

Logging

Display

Diags

Help

Main Menu

Alarm Thresholds

Load: 20.0 kVA

Runtime: 0 hr 0 min

Alarm Threshold Screen

Display setup

Language: English

Contrast: 0
Beeper Setup

Display Setup Menu
