Overview – Display Overview
990-2818A Smart-UPS® VT ISX 20-30 kVA, 200 V Operation 7
Basic display navigation principles
On the display, press ESC until you get to the Overview Screen, which provides you with basic system
status information.
Press UP, DOWN arrows to navigate the selector arrow and view all sub-menu screens.
Press ENTER to open the Main Menu screen. From here, you command, configure, and monitor the
system.
Control functions
From the Control screen on the Main Menu, you can select the following functions:
• Switch Load OFF/ON
• Switch the UPS into Bypass/out of Bypass
Switch load OFF (disconnect the UPS output to the load equipment):
• From the Main Menu, select Control and press ENTER
• Use UP/DOWN key to navigate to Turn Load Off, and press ENTER
• Select YES, Turn Load Off
Note
All illustrated display screens are examples only!
Chrg 100%
Load 000%
200Vin 000Vout 60Hz
Runtime: 0hr 0m
Overview Screen
Control
Status
Setup
Logging
Display
Diags
Help
Main Menu
Warning
Disconnecting the UPS output to the load, does NOT de-energize the UPS! Always
follow the Total-Power-OFF procedure if you need to de-energize the UPS in
emergency situations!
Control
Status
Setup
Logging
Display
Help
Diags
Main Menu
