CS5560
4 DS713PP2
5/4/09
1. CHARACTERISTICS AND SPECIFICATIONS
• Min / Max characteristics and specifications are guaranteed over the specified operating conditions.
• Typical characteristics and specifications are measured at nominal supply voltages and T
A
= 25°C.
• VLR = 0 V. All voltages with respect to 0 V.
ANALOG CHARACTERISTICS
T
A
= -40 to +85 °C; V1+ = V2+ = +2.5 V, ±5%; V1- = V2- = -2.5 V,
±5%; VL -VLR = 3.3 V, ±5%; VREF = (VREF+) - (VREF-) = 4.096V; MCLK = 16 MHz; SMODE = VL.
BUFEN = V1+ unless otherwise stated. Connected per
Figure 6 . Bipolar mode unless otherwise stated.
1. No missing codes is guaranteed at 24 bits resolution over the specified temperature range.
2. One LSB is equivalent to (2 x VREF) ÷ 2
24
or (2 x 4.096) ÷ 16,777,216 = 488 nV.
3. Scales with MCLK.
Parameter Min Typ Max Unit
Accuracy
Linearity Error - 0.0005 - ±%FS
Differential Linearity Error (Note 1, 2) - ±0.1 - LSB
24
Positive Full-scale Error - 1.0 - %FS
Negative Full-scale Error - 1.0 - %FS
Full-scale Drift (Note 2) - 1 - ppm / °C
Unipolar Offset (Note 2) - +2000 - LSB
24
Unipolar Offset Drift (Note 2) - 2 - LSB / °C
Bipolar Offset (Note 2) - ±1000 - LSB
24
Bipolar Offset Drift (Note 2) - 1 - LSB / °C
Noise - 9.5 - μVrms
Dynamic Performance
Peak Harmonic or Spurious Noise 997 Hz, -0.5 dB Input - -111 - dB
Total Harmonic Distortion 997 Hz, -0.5 dB Input - -108 -95 dB
Signal-to-Noise 108 110 - dB
S/(N + D) Ratio -0.5 dB Input, 997 Hz
-60 dB Input, 997 Hz
95
-
109
50
-
- dB
dB
-3 dB Input Bandwidth (Note 3) - 42 - kHz
