AIN1+
AIN1-
AIN2+
AIN2-
CRYSTAL
4.096 MHz
Ext
Ref
Gnd
GND
CS5550
RESET
INT
SCLK
SDO
SDI
CS
C8051F320
Microcontroller
RESET
CIRCUITRY
USB
CONNECTOR OUT IN
+5 V
VREF
Selectable
Divider
Interface Header
AIN1+
AIN1-
AIN2+
AIN2-
AIN1+
AIN1-
AIN2+
AIN2-
CRYSTAL
4.096 MHz
Ext
Ref
Gnd
GND
CS5550
RESET
INT
SCLK
SDO
SDI
CS
C8051F320
Microcontroller
RESET
CIRCUITRY
USB
CONNECTOR OUT IN
+5 V
VREF
Selectable
Divider
Interface Header
AIN1+
AIN1-
AIN2+
AIN2-
\
CDB5550
CDB5550 Evaluation Board and Software
Features
USB Communication with PC
On-board Microcontroller
Multiple Voltage Reference Options
- On-chip Reference
- External Reference with On-Board Precision
Dividers
LabWindows/CVI TM Evaluation Software
- Register Setup & Chip Control
- FFT Analysis
- Time Domain Analysis
- Noise Histogram Analysis
Interface Header for External Microcontroller
Supports 3.3 V and 5.0 V Digital Operation of
the CS5550
General Description
The CDB5550 is an excellent means for quickly evaluat-
ing the functionality and performance of the CS5550 A/D
converter. The CS5550 datasheet is supplied in con-
junction with the CDB5550 evaluation board.
The evaluation board includes a C8051F320 microcon-
troller, a USB interface, drivers, and firmware. The
microcontroller controls the serial communication be-
tween the evaluation board and the PC via the firmware,
enabling quick and easy access to all of the CS5550’s
registers and functions.
The CDB5550 includes software for Data Capture, Time
Domain Analysis, Histogram Analysis, and Frequency
Domain Analysis.
ORDERING INFORMATION
CDB5550 Evaluation Board
JUN ‘04
DS630DB1
