2.3.10 Configuration Register Description
PSS (Power Save Select)[31]
0 Standby Mode (Oscillator active, allows quick power-up).
1 Sleep Mode (Oscillator inactive).
PDW (Power Down Mode)[30]
0 Normal Mode
1 Activate the power save select mode.
RS (Reset System)[29]
0 Normal Operation.
1 Activate a Reset cycle. See System Reset Sequence in the datasheet text.
RV (Reset Valid)[28]
0 Normal Operation
1 System was reset. This bit is read only. Bit is cleared to logic zero after the configuration register is read.
IS (Input Short)[27]
0 Normal Input
1 All signal input pairs for each channel are disconnected from the pins and shorted internally.
NU (Not Used)[26]
0 Must always be logic 0. Reserved for future upgrades.
VRS (Voltage Reference Select)[25]
0 2.5 V < V
REF
≤ [(VA+) - (VA-)]
1 1 V ≤ V
REF
≤ 2.5V
A1-A0 (Output Latch bits)[24:23]
The latch bits (A1 and A0) will be set to the logic state of these bits when the Configuration register is written.
Note that these logic outputs are powered from VA+ and VA-.
00 A1 = 0, A0 = 0
01 A1 = 0, A0 = 1
10 A1 = 1, A0 = 0
11 A1 = 1, A0 = 1
NU (Not Used)[22:20]
0 Must always be logic 0. Reserved for future upgrades.
Filter Rate Select, FRS[19]
0 Use the default output word rates.
1 Scale all output word rates and their corresponding filter characteristics by a factor of 5/6.
NU (Not Used)[18:15]
0 Must always be logic 0. Reserved for future upgrades.
D31(MSB) D30 D29 D28 D27 D26 D25 D24 D23 D22 D21 D20 D19 D18 D17 D16
PSS PDW RS RV IS NU VRS A1 A0 NU NU NU FRS NU NU NU
D15 D14 D13 D12 D11 D10 D9 D8 D7 D6 D5 D4 D3 D2 D1 D0
NU WR3 WR2 WR1 WR0 UP/BP OCD NU NU NU NU NU NU NU NU NU
