CS5371 CS5372
DS255F3 5
DIGITAL CHARACTERISTICS
Notes:T
A
= 25 C; VA+ = 5V or 2.5V ±5%; VA- = 0V or -2.5V ±5%;
VD = 5V or 3.3V ± 5%; DGND = 0V; All voltages with respect to DGND.
ABSOLUTE MAXIMUM RATINGS
Notes:DGND = 0 V
Notes: 12. VA+ and VA- must satisfy {(VA+) - (VA-)} < +6.8 V.
13. VD and VA- must satisfy {(VD) - (VA-)} < +7.6 V.
14. Includes continuous over-voltage conditions at the analog input (AIN) pins.
15. Transient current of up to 100 mA can be safely tolerated without SCR latch-up.
16. Total power dissipation, including all input and output currents.
Parameter Symbol Min Typ Max Unit
High-level Input Voltage V
IH
0.6 * VD - VD V
Low-level Input Voltage V
IL
0.0 - 0.8 V
High-level Output Voltage I
out
= -5.0 mA V
OH
(VD) - 1.0 - - V
Low-level Output Voltage I
out
= 5.0 mA V
OL
- - 0.4 V
Input Leakage Current I
in
- ±1 ±10 µA
3-state Leakage Current I
OZ
- - ±10 µA
Digital Output Pin Capacitance C
out
- 9 - pF
Parameter Symbol Min Typ Max Unit
DC Power Supplies (Notes 12 and 13) Positive Digital
Positive Analog
Negative Analog
VD
VA+
VA-
-0.3
-0.3
-3.3 -
-
- +6.0
+6.0
+0.3 V
V
V
Input Current, Any Pin Except Supplies (Note 14 and 15) I
IN
- - ±10 mA
Input Current, Supplies (Note 15) I
IN
- - ±50 mA
Output Current I
OUT
- - ±25 mA
Power Dissipation (Note 16) PDN - - 500 mW
Analog Input Voltage All Analog Pins V
INA
(VA-) - 0.5 - (VA+) + 0.5 V
Digital Input Voltage All Digital Pins V
IND
-0.5 - (VD) + 0.5 V
Ambient Operating Temperature T
A
-40 - 85 °C
Storage Temperature T
stg
-65 - 150 °C
