CS5371 CS5372
DS255F3 17
INF-
_
Fine Inverting Input, pin 3
Fine inverting analog input.
VREF+
_
Positive Voltage Reference Input, pin 5
Input for an external +2.5 V voltage reference relative to VREF-.
VREF-
_
Negative Voltage Reference Input, pin 6
This pin should be tied to VA-.
Digital Inputs
MCLK
_
Modulator Clock Input, pin 19
A CMOS compatible clock input for the modulator internal master clock, nominally 2.048 MHz
with an amplitude equal to the VD digital power supply.
MSYNC
_
Modulator Sync Input, pin 20
A low to high transition resets the internal clock phasing of the modulator. This assures the
sampling instant and modulator data output are synchronous to the external system.
OFST
_
Offset Mode Select, pin 14
When high, adds approximately -50 mV of offset to the analog inputs to guarantee any
∆Σ idle
tones are removed. When low, no offset is added.
LPWR
_
Low Power Mode Select, pin 23
When set high with MCLK operating at 1.024 MHz, modulator power dissipation is reduced to
15 mW per channel.
PWDN
_
Power-down Mode, pin 24
When high, the modulator is in power-down mode and consumes 1 mW. Halting MCLK while
in power down mode reduces modulator power dissipation to 10
µW .
Digital Outputs
MDATA
_
Modulator Data Output, pin 21
Modulator data is output as a 1-bit serial data stream at 512 kHz with an MCLK input of
2.048 MHz. Modulator data is output at 256 kHz with an MCLK input of 1.024 MHz.
MFLAG
_
Modulator Flag Output, pin 22
A high level output indicates the modulator is unstable due to an over-range on the analog
inputs.
