CS5330A/31A
ANALOG INPUT CHARACTERISTICS
(-1 dBFS input sine wave, 997 Hz; Measurement Bandwidth is 10 Hz to 20 kHz unless otherwise specified; Logic
0 = 0V, Logic 1 = VD+)
4. Referenced to typical full-scale input voltage.
5. Internal highpass filter removes offset.
Parameter Symbol
CS5330A/31A-KSZ
Min Typ Max
CS5330A-BSZ
CS5331A-DSZ
Min Typ Max Unit
Dynamic Performance
Dynamic Range A-weighted
unweighted
88
86 94
92 -
- 86
84 94
92 -
- dB
dB
Total Harmonic Distortion + Noise
(Note 4) -1 dB
-20 dB
-60 dB
THD+N
-
-
- -84
-72
-32 75
66
26 -
-
- -84
-72
-32 75
66
26 dB
dB
dB
Total Harmonic Distortion -1 dB THD - 0.003 0.02 - 0.003 0.2 %
Interchannel Phase Deviation - 0 - - 0 - Degree
Interchannel Isolation (DC to 20 kHz) - 90 - - 90 - dB
DC Accuracy
Interchannel Gain Mismatch - 0.1 - - 0.1 - dB
Gain Error - - ±10 - - ±10 %
Gain Drift - 150 - - 150 - ppm/°C
Offset Error (Note 5) - - 0 - - 0 LSB
Analog Input
Full-scale Input Voltage VIN 3.6 4.0 4.4 3.6 4.0 4.4 Vpp
Input Impedance (Fs = 48 kHz) ZIN - 100 - - 100 - k

Input Bias Voltage 2.2 2.4 2.6 2.2 2.4 2.6 V
Power Supplies
Power Supply Current VA+
Power down
IA+ -
- 30
100
42
1000
-
- 30
100
42
1000
mA
µA
Power Dissipation Normal
Power down
-
- 150
0.5
220
5.25
-
- 150
0.5
220
5.25
mW
mW
Power Supply Rejection Ratio PSRR - 50 - - 50 - dB
* Refer to Parameter Definitions at the end of this data sheet.
