4 DS138F6
CS5330A/31A
2. CHARACTERISTICS AND SPECIFICATIONS
(All Min/Max characteristics and specifications are guaranteed over the Specified Operating Conditions. Typical
performance characteristics and specifications are derived from measurements taken at nominal supply voltages
and T
A
= 25
C.)
SPECIFIED OPERATING CONDITIONS
(AGND = 0V, all voltages with respect to ground)
ABSOLUTE MAXIMUM RATINGS
(AGND = 0V, all voltages with respect to ground.) (Note 1)
Notes:
1. Operation at or beyond these limits may result in permanent damage to the device. Normal operation
is not guaranteed at these extremes.
2. Any pin except supplies. Transient current of up to +/- 100 mA on the analog input pins will not cause
SCR latch-up.
3. The maximum over/under voltage is limited by the input current.
Parameter Symbol Min Typ Max Unit
Analog Supply Voltage VA+ 4.75 5.0 5.25 V
Ambient Operating Temperature (Power Applied) KSZ
BSZ, DSZ
T
A
-10
-40 -
- +70
+85 °C
°C
Parameter Symbol Min Typ Max Unit
Analog Supply Voltage VA+ -0.3 - +6.0 V
Input Current, Any Pin Except Supplies (Note 2) lin - - ±10 mA
Analog Input Voltage (Note 3) V INA -0.7 - VA+0.7 V
Digital Input Voltage (Note 3) V IND -0.7 - VA+0.7 V
Ambient Temperature (power applied) T A -55 - +125 °C
Storage Temperature T stg -65 - +150 °C
