DS568F1 33
CS4398
7.4 Mute Control - Register 04h
7.4.1 PCM Auto-mute (PAMUTE) Bit 7
Function:
When set to 1 (default), the Digital-to-Analog converter output will mute following the reception of 8192
consecutive audio samples of static 0 or -1. A single sample of non-static data will release the mute. De-
tection and muting is done independently for each channel. The quiescent voltage on the output will be
retained, and the Mute Control pin will go active during the mute period.
When set to 0, this function is disabled.
7.4.2 DSD Auto-mute (DAMUTE) Bit 6
Function:
When set to 1 (default), the Digital-to-Analog converter output will mute following the reception of 256 re-
peated 8-bit DSD mute patterns (as defined in the SACD specification).
A single bit not fitting the repeated mute pattern (mentioned above) will release the mute. Detection and
muting is done independently for each channel. The quiescent voltage on the output will be retained, and
the Mute Control pin will go active during the mute period.
When set to 0, this function is disabled.
7.4.3 AMUTEC = BMUTEC (MUTEC A=B) Bit 5
Function:
When set to 0 (default) the AMUTEC and BMUTEC pins operate independently.
When set to 1, the individual controls for AMUTEC and BMUTEC are internally connected through an
AND gate prior to the output pins. Therefore, the external AMUTEC and BMUTEC pins will go active only
when the requirements for both AMUTEC and BMUTEC are valid.
7.4.4 A Channel Mute (MUTE_A) Bit 4
B Channel Mute (MUTE_B) Bit 3
Function:
When set to 1, the Digital-to-Analog converter output will mute. The quiescent voltage on the output will
be retained. The muting function is effected, similar to attenuation changes, by the Soft and Zero Cross
bits in the Volume and Mixing Control register. The corresponding MUTEC pin will go active following any
ramping due to the soft and zero cross function.
When set to 0 (default), this function is disabled.
7 6 5 4 3 2 1 0
PAMUTE DAMUTE MUTEC A=B MUTE_A MUTE_B Reserved MUTEP1 MUTEP0
1 1 0 0 0 0 0 0
