10 REVISION HISTORY

Revision

Changes

DB1

– Initial Release

DB2

– Updated

“Features” on page 1

to remove list of optional single-ended input filters.

– Added description of interrupt pull-up behavior in

Section 1.8 on page 5

.

– Removed single-ended input filter descriptions from

Section 1.9 on page 6

.

– Updated

Section 1.10 on page 6

.

– Updated

Section 2

to reflect latest FlexGUI software version.

– Updated

Figure 5 on page 13

.

– Updated

Section 3.1 on page 13

.

– Updated

Section 3.2 on page 14

.

– Removed single-ended filter descriptions from

Section 4

.

– Added

Section 4.1

and

Section 4.2 on page 15

.

– Removed single-ended input filter configurations from

Table 1 on page 16

.

– Updated capacitor voltage ratings in

Table 1 on page 16

and

Table 2 on page 19

.

– Updated

Figure 8 on page 17

.

– Updated

Section 5.1 on page 17

.

– Changed label of connector J8 in

Table 3 on page 20

and

Figure 12 on page 25

.

– Added

Note 5

,

Note 6

,

Note 8

, and

Note 9

under

Table 3 on page 20

.

– Changed default position of jumper J61 in

Table 4 on page 21

.

– Updated

Figure 9 on page 22

.

– Added R25 to

Figure 11 on page 24

.

– Updated

Section 9

to reflect latest PCB layout.

Contacting Cirrus Logic Support

For all product questions and inquiries, contact a Cirrus Logic Sales Representative.
To find the one nearest you, go to

www.cirrus.com.
