WIKA Operating Instructions Hand-Held Pressure Indicator 19
3.2 Func-CYCL“: Automatic datalogging with adjustable
cycle-time
The Logger cycle-time is adjustable (see Configuration). For example,
setting “CYCL“ = 60: A measurement is made every 60 seconds.
When the slow measurement “rAtE-Slo“ is chosen, additionally a low
power function is available: “Lo.Po“.
If “Lo.Po“ is on, the device only will take a measurement at the point of
time of the recording. In between the recordings the measuring shut‘s
down. This decreases the power consumption enormously and there-
fore is recommended e.g. for long time recordings where no mains
adapter is available.
Max. number of measurements: CPH6200-S1: 10000
CPH6200-S2: 4000
(at max. 64 recording sequences)
Cycle-time: 1 ... 3600 seconds (=1 h), selectable
from the configuration menu
A measurement contains:
Slow measuring rate (rAtE-SLo):
- Sensor 1 current value at that data point
- Sensor 1 Min-Peak, Max-Peak since last data point
- Sensor 2* instantaneous value at that data point
- Sensor 2* Min-Peak, Max-Peak since last data point
- Instantaneous difference (Sensor 1 - Sensor 2)* at that data point
- Min-Peak, Max-Peak of difference (Sensor 1 - Sensor 2)*, Min-
Peak, Max-Peak since last data point
Fast measuring rate (rAtE-FASt, -P.dEt):
- Sensor 1 average since last data point
- Sensor 1 Min-Peak, Max-Peak since last data point
- Sensor 2* average since last data point
- Sensor 2* Min-Peak, Max-Peak since last data point
- Average difference (Sensor 1 - Sensor 2)* since last data point
- Min-Peak, Max-Peak of difference (Sensor 1 - Sensor 2)*,
Min-Peak, Max-Peak since last data point
* Only for 2-channel version CPH6200-S2


