WIKA Operating Instructions Hand-Held Pressure Indicator 12
Menu Param. Setting Meaning
„Menu“ ► ▲ or ▼
SEt
AL.
Set Alarm: Alarm function configuration
AL.
[1,2,DIF] on Alarm function on, with audio alarm
no. So Alarm function on without audio alarm
oFF No alarm function
AL.Lo
[1,2,DIF] Min-Range ...
... AL.Hi Min alarm limit
(not when AL.oFF, Min-Range is the lower display range of the
connected sensor)
AL.Hi
[1,2,DIF] AL.Lo ...
... Max-Range Max alarm limit
(not when AL.oFF, Max-Range is the upper display range of the
connected sensor)
SEt
LoGG Set Logger: Logger function configuration *
Func CYCL Cyclic: logger function ‘cyclic logger’ *
Stor Store: logger function ‘discrete value logger’ *
oFF No logger function *
CYCL 1 ... 3600 Cycle time for cyclic logger [seconds] *
Lo.Po on / oFF Low-power logger with very low power consumption (only if
cyclic logger with slow measuring rate) *
SEt
CLOC Set Clock: Setting of real time clock *
CLOC HH:MM Clock: set time hours:minutes
dAtE TT.MM Date: set time day.month
YEAr YYYY Year: set time year
* If there is existing data in the logger memory, the menus/parameters
cannot be accessed! If these need to be adjusted, the logger memory
must first be cleared! (see Section “3. Operation of logger”.)
** This menu can oly be invoked if a refering sensor is connected to
connection 1. When using a second sensor at connection 2 then
changes are taken over.
2. Configuration
To change device settings, press the ´Set/Menu´ key for 2 seconds. This
will access the configuration menu (main display: “SEt“).
Pressing the
´Set/Menu´ key again scrolls down the menus, pressing
the ´Tare´ key scrolls across to the associated parameters, which can
then be selected with the ´Tare´ key.
The parameters can be altered using the ´Min´ or ´Max´ keys. Pressing
the ´Set/Menu´ key again saves the settings and returns you to the main
configuration menu.
The
´Store/Quit´ key exits the configuration and returns you to standard
measuring mode.
