9 WIKA operating instructions level switch model LSD-30
GB
11613033.01 01/2012 GB/D/F/E
3. Specifications
3. Specifications
3.1 Measuring ranges
for parallel process connections
Probe length F 250 370 410 520 730
mm 189 309 349 459 669
inch 7.44 12.17 13.74 18.07 26.34
for tapered process connections
Probe length F 250 370 410 520 730
mm 205 325 365 475 685
inch 8.07 12.80 14.37 18.70 26.93
Insertion lengths see "Insertion lengths in mm"
Specific gravity range of the medium
≥ 0.7 g/cm
3
3.2 Display
14-segment LED, red, 4-digit, character size 9 mm
Display can be turned electronically through 180°
Update
200 ms
