Page 14
14
WIKA operating instructions level switch model LSD-30
GB
11613033.01 01/2012 GB/D/F/E
3.10 Approvals, directives and certificates
CE conformity
EMC directive:
2004/108/EC, EN 61326-2-3 emission (group 1, class B) and interference immunity
(industrial application)
RoHS conformity: Yes
3.11 Electrical connections
Connections
Circular connector M12 x 1, 4-pin
Circular connector M12 x 1, 5-pin (only for version with SP1, SP2 and S
+
)
Ingress protection
IP 65 and IP 67
The stated ingress protection (per IEC 60529) only applies when plugged in using mating connectors that have the appropriate ingress
protection.
Electrical safety
Short-circuit resistance:
S
+
/ SP1 / SP2 vs. U-
Reverse polarity protection: U
+
vs. U-
Insulation voltage:
DC 500 V
Overvoltage protection:
DC 40 V
For further specifications see WIKA data sheet LM 40.01 and the order documentation.
3. Specifications
