Emergency Message (EMCY) Slave sends
Telegram structure
ID DLC Byte 0 Byte 1 Byte2
80h + Node-ID 8
LSB
Emergency error Code
MSB
Emergency error Code Error Register (1001h)
Byte Byte 4 Byte 5 Byte 6 Byte 7
Manufacturer -specific
error
Manufacturer -specific
error
Unused Unused Unused
Error Code Meaning
00 00h No error
10 00h Generic error
FF 00h Device specific error
Byte Byte 4 Byte 5 Byte 6 Byte 7
00h 00h 00h
If the problem persists, contact our sales department.
Process material certificate (Contamination declaration for returned goods)
Purge / clean dismounted instruments before returning them in order to protect our employees
and the environment from any hazard caused by adherent remaining media.
Service of instruments can only take place safely when a Product Return Form has been
submitted and fully filled-in. This Return Form contains information on all materials with which
the instrument has come into contact, either through installation, test purposes, or cleaning.
You can find the Product Return Form on our internet site (www.wika.de / www.wika.com).
9. Trouble shooting GB 9. Trouble shooting / 10. Storage, disposal GB
10. Storage, disposal
When storing or disposing of the pressure transmitter, take precautions with
regard to remaining media in removed pressure transmitters. We recom-
mend cleaning the transmitter properly and carefully. Remaining media in
the pressure port may be hazardous or toxic!
Mount the protection cap when storing the pressure transmitter in order to prevent any
damage to the diaphragm (D-21-9).
Dispose of instrument components and packaging materials in accordance with the
respective waste treatment and disposal regulations of the region or country to which
the instrument is supplied.
Storage
Disposal
WIKA reserves the right to alter these technical specifications.
This applies only for error reports which are sent by means of emergency messages.
The error register supports only error 1 (= general error).
Error Coding
Not used (always 0)
Internal error
XXXX XXX1: Error while EPROM write
XXXX XX1X: Not used
XXXX X1XX: Max. allowed pressure exceeds
XXXX 1XXX: Min. allowed pressure exceeds
!
Warning
