Specifications Model D-20-9, D-21-9
Adjustability zero/span % +/- 10 by entries into object directory
Response time (10 … 90 %) ms 1.5 (Baud rate ≥ 125 K)
Internal measuring rate Hz 1000 (adjustable to approx. 4 Hz)
Accuracy % of span ≤ 0.5 {0.25 or 0.15} 4) (BFSL)
≤ 1 5) {0.5 or 0.3} 4) 5)
4) Accuracy 0.3% 5) or 0.15% (BFSL) is not available in combination with DIP-switch.
5) Including non-linearity, hysteresis, zero point and full scale error (corresponds to
error of measurement per IEC 61298-2).
Adjusted in vertical mounting position with lower pressure connection.
Non-linearity % of span ≤ 0.2 (BFSL) according to IEC 61298-2
Non-repeatability % of span ≤ 0.1
1-year stability % of span ≤ 0.2 (at reference conditions)
Permissible temperature of
Medium
6) *) -30 … +100 °C {-40 … +125 °C} -22 ... +212 °F {-40 ... +257 °F}
Ambience 6) -20 ... +80 °C -4 ... +176 °F
Storage 6) -40 ... +100 °C -40 ... +212 °F
6) Also complies with EN 50178, Tab. 7, Operation (C) 4K4H, Storage (D) 1K4,
Transport (E) 2K3
Compensated temp range 0 ... +80 °C 32 ... +176 °F
Temperature coefficients within
compensated temp range
Mean TC of zero  % of span ≤ 0.2 / 10 K
Mean TC of range  % of span ≤ 0.2 / 10 K
CE- conformitiy
Pressure equipment directive  97/23/EC
EMC directive  89/336/EEC emission (class B) and immunity according to EN 61 326
Shock resistance g 500 according to IEC 60068-2-27 (mechanical shock)
Vibration resistance g 20 7) according to IEC 60068-2-6 (vibration under resonance)
Specifications Model D-20-9, D-21-9
7) Only with option DIP switch, otherwise 10 g.
Wiring protection
Reverse polarity protection  UB+ against UB-
Weight kg
Approx. 0.2
Approx. 0.3 option with integrated Y-piece
7. Starting, operation GB
Functional test
Open pressure connections only after the system is without pressure!
Observe the ambient and working conditions outlined in section 7 „Technical
data".
Please make sure that the pressure transmitter is only used within the over-
load threshold limit at all times! 


When touching the pressure transmitter, keep in mind that the surfaces of
the instrument components might get hot during operation.
When designing your plant, take into account that the stated values (e.g.burst pressure,
over pressure safety) apply depending on the material, thread and sealing element used.
The output signal must be proportional to the pressure. If not, this might point to a
damage of the diaphragm. In that case refer to chapter 9 „Troubleshooting“.
7. Starting, operation GB
*) In an oxygen version model D-21-9 is not available. In an oxygen version model D-20-9 is only available with media temperatures
between -4 … +140 °F / -20 … +60 °C and using stainless steel or Elgiloy ® wetted parts.
{ } Items in curved brackets are optional extras for additional price.
Warning
Caution
