2059064.04 GB/D/F/E 06/2008

64 WIKA Operating instructions/Betriebsanleitung/Mode d'emploi/Instrucciones de servicio D-2X-9

2059064.04 GB/D/F/E 06/2008

65

WIKA Operating instructions/Betriebsanleitung/Mode d'emploi/Instrucciones de servicio D-2X-9

Index Sub-

Index Name

Type

Attr Default

Value

Remarks

1

Vendor ID

unsigned int 32 ro

00 00 00 47 h

2

Product code

unsigned int 32 ro

3

Revision number

unsigned int 32 ro

4

Serial number

unsigned int 32 ro

1800 h

transmit PDO communication

parameter

0

number of entries

unsigned int 8

ro

05 h

1

COB-ID used by PDO

unsigned int 32 rw

00 00 01 81 h

Only 180h, 200h, 280h, 300h,

380h, 400h, 480h, 500h

+ Node-ID allowed

2

transmission type

unsigned int 8

rw

01 h

only 01h-F0h, FEh allowed

3

Res.

4

Res.

5

event timer

unsigned int 16 rw

1A00 h

transmit PDO mapping para-

meter

0

number of mapped objects

unsigned int 8

rw

01 h

1

PDO mapping for the 1. appli-

cation object to be mapped

unsigned int 32 rw

20 90 00 20 h 61300120h or 20900020h

Index Sub-

Index Name

Type

Attr Default

Value

Remarks

2010 h 0

minimum allowed pressure

unsigned int 16 rw

00 00 h

2011 h 0

maximum allowed pressure

unsigned int 16 rw

FF FF h

2090 h 0

processvalue as integer

int 32

ro

2100 h 0

user device name

unsigned int 32 rw

FF FF FF FF h

2201 h 0

last calibration date year

unsigned int 8

rw

YY

Index Sub-

Index Name

Type

Attr Default

Value

Remarks

6110 h

Al_Sensor_Type

0

number of entries

unsigned int 8

ro

01 h

1

Al_Sensor Type_1

unsigned int 16 ro

00 5A h

Pressure transducer

6114 h

Al_ADC_Sample_Rate

0

number of entries

unsigned int 8

ro

01 h

1

Al_ADC_Sample_Rate_1

unsigned int 32 rw

1000

In µs(min. 1000, max 255000,

only multiple of 1000 allowed

6121 h

AI_Input_Scaling_1_PV

0

number of entries

unsigned int 8

ro

01 h

1

AI_Input_Scaling_1_PV_1

float

rw

Al_Span_Start

6123 h

AI_Input_Scaling_2_PV

0

number of entries

unsigned int 8

ro

01 h

Index Sub-

Index Name

Type

Attr Default

Value

Remarks

2202 h 0

last calibration date month

unsigned int 8

rw

MM

2203 h 0

last calibration date day

unsigned int 8

rw

DD

2207 h 0

date of production year

unsigned int 8

ro

YY

2208 h 0

date of production month

unsigned int 8

ro

MM

2209 h 0

date of production day

unsigned int 8

ro

DD

2302 h 0

measure mode

unsigned int 8

ro

00h = rel.; 01h = abs

2320 h 0

configure Node-ID

unsigned int 8

rw

01 h

only 1 .. 127 allowed, settings

take effect after reset

2321 h 0

configure bit timing

unsigned int 8

rw

03 h

only 0 ..7 allowed, settings

take effect after reset (entry

acc. CiA bit timing table)

11. Object Dictionary / Objektverzeichnis / Dictionnaire d‘objet / Diccionario Objeto

Manufacturers Specific Profile Area / Zone profil spécifique du fabricant / Profile Area
específica del fabricante

11. Object Dictionary / Objektverzeichnis / Dictionnaire d‘objet / Diccionario Objeto

Object Dictionary - Device Profile Area (according to / gemäß / selon / de acuerdo a
CiA DP 404)
