WIKA D-21-9 - Manual (Page 34)

2059064.04 GB/D/F/E 06/2008
66 WIKA Operating instructions/Betriebsanleitung/Mode d'emploi/Instrucciones de servicio D-2X-9
2059064.04 GB/D/F/E 06/2008
67 WIKA Operating instructions/Betriebsanleitung/Mode d'emploi/Instrucciones de servicio D-2X-9
Index Sub-
Index Name
Type Attr Default
Value
Remarks
1 AI_Input_Scaling_2_PV_2 float rw Al_Span_End
6124 h AI_Input_Offset
0 number of entries unsigned int 8 ro 01 h
1 AI_Input_Offset_1 float rw
6125 h AI_Autozero0
0 number of entries unsigned int 8 ro 01 h
1 AI_Autozero_1 unsigned int 32 wo
By writing the signature 6F 72
65 7A h (zero)
6130 h AI_Input_PV
0 number of entries unsigned int 8 ro 01 h
1 Al_Input_PV_1 float ro
6131 h AI_Physical_Unit_PV
0 number of entries unsigned int 8 ro 01 h
1 AI_Physical_Unit_PV_1 unsigned int 32 00 22 00 00 h (=Pa)
6132 h
0 number of entries unsigned int 8 ro 01 h
1 AI_Decimal_Digits_1 unsigned int 8 rw 0 Only 0 .. 9 allowed
6148 h AI_Span_Start
0 number of entries unsigned int 8 ro 01 h
1 AI_Span_Start_1 float ro
6149 h AI_Span_End_1
0 number of entries unsigned int 8 ro 01 h
1 AI_Span_End_1 float ro
61A0 h Al_Filter_Type
0 number of entries unsigned int 8 ro 01 h
1 Al_Filter_Type_1 unsigned int 8 ro 64 h (= Manufacturer Specific)
61A1 h Al_Filter_Constant
Index Sub-
Index Name
Type Attr Default
Value
Remarks
0 number of entries unsigned int 8 ro 01 h
1 Al_Filter_Constant_1 unsigned int 8 rw 08 h Only 1 ... 128 allowed
7100 h Al_Input_FV
0 number of entries unsigned int 8 ro 01 h
1 Al_Input_FV_1 unsigned int 16 ro
7120 h Al_Input_Scaling_1_FV
0 number of entries unsigned int 8 ro 01 h
1 Al_Input_Scaling_1_FV_1 unsigned int 16 ro 10000 d
7122 h Al_Input_Scaling_2_FV
0 number of entries unsigned int 8 ro 01 h
1 Al_Input_Scaling_2_FV_1 unsigned int 16 ro 60000 d
11. Object Dictionary / Objektverzeichnis / Dictionnaire d‘objet / Diccionario Objeto 11. Object Dictionary / Objektverzeichnis / Dictionnaire d‘objet / Diccionario Objeto
