Technical Specifications
17
Table 9: Technical Specifications of the 711xl and the 712xl
711xl 712xl
INPUT: Video, 1Vpp/75 on a BNC connector;
audio 1Vpp / 33k on RCA connectors
6-pole detachable terminal block
connector
OUTPUT: 6-pole detachable terminal block
connector
Video, 1Vpp/75 on a BNC connector;
audio 1Vpp / 150 on RCA connectors
MAX. SIGNAL LEVEL: 2.1Vpp (video), 4.2Vpp (audio)
VIDEO BANDWIDTH (-3dB): 45MHz
AUDIO BANDWIDTH (-3dB): 100kHz
DIFF. GAIN:
1.4%
DIFF. PHASE: 0.6 Deg.
VIDEO S/N RATIO: 76dB
AUDIO S/N RATIO: 77dB unweighted
AUDIO THD + NOISE: 0.033%, 1kHz
AUDIO 2nd HARMONIC: 0.002%
MAX. SIGNAL LEVEL: 1.7Vpp (video), 4.2Vpp (audio)
POWER SOURCE: 12 VDC 80mA
DIMENSIONS: 12cm x 7.5cm x 2.5cm (4.7” x 2.95” x 0.98”, W, D, H.)
WEIGHT: 0.28kg. (0.62lbs.) approx. (each)
ACCESSORIES: Power supply, mounting bracket (each)
OPTIONS: RK-T1, RK-T3, 19 inch rack adapters
