Technical Specifications
16
7 Technical Specifications
1
Table 7 includes the technical specifications of the
TP-1xl and the TP-2xl,
Table 8 includes the technical specifications of the
708, and Table 9 includes
the technical specifications of the
711xl, and the 712xl:
Table 7: Technical Specifications of the TP-1xl and the TP-2xl
TP-1xl
TP-2xl
INPUT:
1 composite video, 1Vpp/75 on a
BNC type connector
4-pin detachable terminal block
OUTPUT:
4-pin detachable terminal block
1 composite video, 1Vpp/75 on a
BNC type connector
VIDEO BANDWIDTH (-3dB): 13MHz at 300 meters
DIFF. GAIN:
2% (@ 20 meters)
CONTROL:
0.9Deg (@ 20 meters)
VIDEO S/N RATIO:
73dB (@ 20 meters)
SYSTEM DELAY:
<1 microsecond TYP. at 100 meters
CONTROLS:
Gain: -3dB to +4.4dB; EQ.: -16dB to +9.9dB @ 4.4MHz
POWER SOURCE:
230 VAC, 50/60Hz, (115VAC, U.S.A.) 4VA each
DIMENSIONS:
16.5cm x 12cm x 4.5cm (6.5” x 4.7” x 1.8”, W, D, H.)
WEIGHT:
0.7kg. (1.6lbs.) approx. (each)
ACCESSORIES:
Power cord (each)
OPTIONS:
RK-50RN, 19” rack adapter holds two units in one vertical rack space
Table 8: Technical Specifications of the 708
INPUTS:
Looping balanced 150 on a 6/4 standard telephone socket, with termination
switch and polarity inversion switch
OUTPUTS:
1 composite video, 1Vpp/75 composite video, 1Vpp/75 unbalanced on a BNC
connector
1 audio - line level, up to 4.6Vpp/100 on an RCA connector
BANDWIDTH:
Video: 58MHz; audio: 30kHz (at 30 meters without lightening arrestors)
NON-LINEARITY:
<0.2% at short distances
DIFF. GAIN:
0.41%
DIFF. PHASE:
0.3 Deg.
K-FACTOR:
0.1% (@ 20m)
S/N RATIO:
72dB
CONTROLS:
Video gain: -1.8dB to +2.3dB, EQ above 2.5 MHz: 0dB to 16dB, audio: 0dB to
52dB; loop termination, signal invert
POWER SOURCE:
12 VDC 40mA
DIMENSIONS:
12cm x 7.5cm x 2.5cm (4.7” x 2.95” x 0.98”, W, D, H.)
WEIGHT:
0.28kg. (0.62lbs.) Approx.
ACCESSORIES:
Power supply, mounting bracket
OPTIONS:
Model VA-50P power supply with six 12VDC outlets; RK-T1, RK-T3, 19” rack
adapters
1 Specifications are subject to change without notice
