The TP-125-od / TP-126-od Transmitter / Receiver Set
24
7 The TP-125-od / TP-126-od Transmitter / Receiver Set
The Kramer TOOLS TP-125-od is a high-performance transmitter that
accepts a computer graphics input signal, an unbalanced stereo analog audio
signal and RS-232 control commands. The stereo analog audio signal is
converted to the digital audio (S/PDIF) stream before transmitting, thus
preserving the quality of the audio source signals.
The TP-125-od codes the signals and transmits them over CAT 5 cable to the
Kramer TOOLS TP-126-od. The TP-126-od outputs a computer graphics
signal, an unbalanced stereo analog audio signal, a converted digital audio
(S/PDIF) signal, and bidirectional RS-232 control commands and data, to and
from the TP-125-od. The RS-232 interface makes it possible to control
virtually any device over a transmission range of more than 300 feet (more than
100 meters) over UTP cabling. The commands and data can flow in both
directions via the RS-232 interface, allowing status requests and control of
the destination unit. The TP-125-od can power or be powered by the
TP-126-od transmitter over the same CAT 5 cable and is 12V DC fed.
When the TP-125-od is connected to a display device and the EDID
CAPTURE button is pressed, the TP-125-od reads and stores the EDID
(Extended Display Identification Data) from the display device. The display can
be disconnected and later reconnected without rebooting the operating system.
In addition, the TP-126-od features:
• Level and EQ. control for the UXGA signals
• 24 bit 48kHz S/PDIF digital audio that supplies the highest quality audio
