Technical Specifications
20
Table 9: Technical Specifications of the 709 and the 710
709
710
INPUTS:
s-Video, 1Vpp/75 (Y), 0.3Vpp/75 (C)
on a 4p connector
4-pin terminal block
OUTPUTS:
4-pin terminal block
s-Video, 1-Vpp/75 (Y), 0.3Vpp/75
(C) on a 4p connector
BANDWIDTH:
8.4MHz, (Y) at 100m
NON-LINEARITY:
0.07%
DIFF. GAIN:
0.04%
K-FACTOR:
1.4% at 100m
S/N RATIO:
Better than 60dB
CONTROLS:
Y gain: -2.4dB to +6.5dB; Y EQ: -2.7dB to 15.6dB; C gain: -5.8dB to 7.8dB
710
: loop termination
POWER SOURCE:
12 VDC 40mA
DIMENSIONS:
12cm x 7.5cm x 2.5cm (4.7” x 2.95” x 0.98”, W, D, H)
WEIGHT:
0.26kg. (0.58lbs.) Approx.
ACCESSORIES:
Power supply, mounting bracket
OPTIONS:
Model VA-50P power supply with six 12VDC outlets; RK-T1, RK-T3, 19” rack
adapters
Table 10: Technical Specifications of the 711xl and the 712xl
711xl
712xl
INPUT:
Video, 1Vpp/75 on a BNC connector;
audio 1Vpp / 33k on RCA connectors
6-pole detachable terminal block
connector
OUTPUT:
6-pole detachable terminal block
connector
Video, 1Vpp/75 on a BNC connector;
audio 1Vpp / 150 on RCA connectors
MAX. SIGNAL LEVEL:
2.1Vpp (video), 4.2Vpp (audio)
VIDEO BANDWIDTH (-3dB): 64MHz
AUDIO BANDWIDTH (-3dB): 100kHz
DIFF. GAIN:
1.4%
DIFF. PHASE:
0.63°
VIDEO S/N RATIO:
76dB
AUDIO S/N RATIO:
76dB unweighted
AUDIO THD + NOISE:
0.033%, 1kHz
AUDIO 2nd HARMONIC:
0.002%
MAX. SIGNAL LEVEL:
1.7Vpp (video), 4.2Vpp (audio)
POWER SOURCE:
12 VDC 80mA
DIMENSIONS:
12cm x 7.5cm x 2.5cm (4.7” x 2.95” x 0.98”, W, D, H)
WEIGHT:
0.28kg. (0.62lbs.) approx.
ACCESSORIES:
Power supply, mounting bracket
OPTIONS:
RK-T1, RK-T3, 19 inch rack adapters
