KRAMER: SIMPLE CREATIVE TECHNOLOGY

The 711xl and 712xl Video-Audio Line Transmitter and Receiver

6 The 711xl and 712xl Video-Audio Line Transmitter and

Receiver

This section:

Describes the

711xl (see section 6.1)

Describes the

712xl (see section 6.2)

Defines the 6-pole detachable terminal block connector pinout (see

section 6.3)

Describes how to connect the

711xl/712xl Video-Audio Line

Transmitter/Receiver (see section 6.4)

The

711xl and 712xl are a twisted pair transmitter and receiver for composite

video and unbalanced stereo audio signals. The

711xl transmitter converts

composite video and stereo audio to a twisted pair signal and the

712xl

receiver converts the twisted pair signal back into composite video and stereo

audio signals.
The

711xl/712xl feature:
A bandwidth of 45MHz
Twisted pair inputs and outputs on terminal block connectors
A system range of up to 1000 meters (more than 3000 feet)
Level (GAIN) and equalization (EQ) controls (for the

712xl)

In addition, the

712xl LINE IN can be looped to add additional outputs and

includes a selectable input signal termination push button.
