The 709 and 710 Y/C Line Transmitter and Receiver
12
5.3 Connecting the 709/710 Y/C Line Transmitter/Receiver
You can use the 709 and 710 to configure a Y/C Transmitter and Receiver system.
To connect the 709 Y/C Line Transmitter with the 710 Y/C Line Receiver, as
illustrated in the example in Figure 6, do the following:
1. Connect an s-Video source (for example, an s-Video camera) to the Y/C
INPUT 4p connector on the 709.
2. On the 710, connect the Y/C OUTPUT 4p connector to an s-Video acceptor
(for example, a display).
3. Connect the C OUT Y OUT terminal block connector of the 709 to the C IN
Y IN terminal connector of the 710, via twisted pair cabling 1 .
4. On each 709 / 710 unit, connect a 12V DC power adapter to the power socket
and connect the adapter to the mains electricity (not shown in Figure 6).
5. On each 709 / 710 unit, if required, adjust the Y GAIN, the C GAIN and the Y
EQ. levels, by inserting a screwdriver into each of the small holes and
carefully rotating them.
6. If required, connect the C IN Y IN terminal block connector of the 710 to the
C IN Y IN terminal block connector 2 of an additional 710 (as illustrated in
Figure 7).
1 A straight connection should be made between the units ( C+ OUT to C+ IN, C- OUT to C- IN, and so on)
2 Connect C+ to the C+ of the next 710, C- to the C- of the next 710, Y+ to the Y+ of the next 710, and Y- to the Y- of the
next 710
