Customizing the Controllers' Buttons and Labels
32
PART IV Further information
PART IV includes further information
10 Customizing the Controllers' Buttons and Labels
This section describes the backlit buttons and the button labels sheet.
10.1 Backlit Buttons
The RC-63DL backlit buttons
1
have plastic caps. To insert a label on a button
(we recommend doing this before installing the controller as it involves
removing the front plate), unscrew the front plate attachment screws using a
screwdriver, gently remove the transparent button cap with your fingers, and
insert the label under the button cap. Replace the button cap with the label
onto the button base.
10.2 Button Label Sheet
Figure 11 illustrates the sample Button Label sheet.
Figure 11: Sample Button Labels Sheet
1 You can program the color of the button with flexible RGB values
