Connecting the VS-88HDxl
11
11
6.2 Connecting the VS-88HDxl in the Dual Link Mode
You can use your VS-88HDxl in the dual-link mode to switch any of the
four dual-link SDI inputs to any or all of the four dual-link SDI outputs, as
shown
1
Figure 3 in the examples in and Figure 4 .
To connect the VS-88HDxl 3G HD/SD-SDI Matrix Switcher in the dual-
link mode, do the following
2
1. Connect up to 4 of the SDI sources to the INPUT DUAL LINK BNC
connectors. For example, a dual-link HD/SD camera to DUAL LINK 1
(inputs 1 and 2) and a dual-link 3G HD video server to DUAL LINK 4
(inputs 7 and 8).
:
2. Connect the SDI OUTPUT BNC connectors to up to four SDI acceptors.
For example, OUTPUT DUAL LINK 3 (outputs 5 and 6) to a dual-link
preview display and OUTPUT DUAL LINK 4 (outputs 7 and 8) to a dual-
link HD SDI mixer.
3. Set the DIP-switches (see section 6.4.2 ).
4. Optionally
3
• A genlock source to the GENLOCK BNC connector
, connect:
• The LOOP BNC connector to the GENLOCK connector of
the next unit in the line, and release the TERM button for
looping4
5. Connect a PC and/or controller (if required), to the:
• RS-232 port (see section
6.4 ), and/or
• RS-485 port (see section
6.5 ), and/or
• ETHERNET connector (see section
6.7 )
6. Connect the power cord
5
7. Set the machine to the dual-link mode (see section
.
6.3 ).
Note: In dual link mode only the first input status LED lights when both
inputs are connected. For example, if inputs 3 and 4 are connected as a dual
link, only the input status LED 3 lights.
1 The graphic on the rear panel does not indicate the dual link connections
2 Switch OFF the power on each device before connecting it to your VS-88HDxl. After connecting your VS-88HDxl, switch
on its power and then switch on the power on each device
3 Not illustrated in Figure 2
4 Pushed in terminates the input. Release when the input extends to another unit
5 We recommend that you use only the power cord that is supplied with this machine
