KRAMER: SIMPLE CREATIVE TECHNOLOGY

Connecting the VS-42HC

6 Connecting the VS-42HC

This section describes how to connect the

VS-42HC. In particular, how to:

Connect the

VS-42HC rear panel (see section 6.1)

Connect the audio signals (see section 6.2)
Set the dipswitches (see section 6.3)

6.1 Connecting the VS-42HC Rear Panel

To connect the

VS-42HC, as the example in Figure 3 illustrates, do the

following

1. Connect up to four component video sources

(for example, four DVD

players) to the three IN RCA connectors Y, Pb/Cb and Pr/Cr (from IN 1

to IN 4) and connect the corresponding digital audio sources to the

S/PDIF

RCA connectors (see section 6.2).

2. Connect

the three OUT 1 RCA connectors Y, Pb/Cb and Pr/Cr to the

video acceptor (for example, a plasma display) and connect the

corresponding OUT 1 S/PDIF RCA connector (see section 6.2) to the

digital audio acceptor (for example, an AV receiver).

3. Connect the three OUT 2 RCA connectors Y, Pb/Cb and Pr/Cr to the

video acceptor (for example, a plasma display) and connect the

corresponding OUT 2 S/PDIF RCA connector and OUT 2 (TOSLINK)

connector (see section 6.2) to the digital audio acceptor (for example, the

audio connector on the digital display).

4. Set the dipswitches (see section 6.3).
5. If required, connect a PC and/or controller to the RS-232 port (see

section 7.1) and/or the RS-485 port (see section 7.2) and/or the

ETHERNET port (see section 7.3).

6. Connect the power cord

1 Switch OFF the power on each device before connecting it to your VS-42HC. After connecting your VS-42HC, switch on
its power and then switch on the power on each device. DO NOT push in the rear panel Flash Program “Flash Upgr.” button
(see Table 3) and DO NOT switch the ETH Flash switch. These are only used for upgrading to the latest Kramer firmware
(see section 9)
2 Although in this example four inputs are connected, you can connect less inputs
3 Or TOSLINK connector for IN 2
4 You do not need to connect both outputs
5 We recommend that you use only the power cord that is supplied with this machine
