Kramer Electronics VP-81SIDN - Manual (Page 8)

4 VP-81SIDN - Overview
3 Overview
The VP-81SIDN can route one of eight TP (Twisted Pair), a DVI or an HDMI input
to either a TP or an HDMI output. Input selection can also be controlled remotely
using;

Step-In modules (for example, the SID-DP)

Contact closure switches

A serial controller via RS-232 or RS-485

A PC via Ethernet connected over a LAN
The device also outputs balanced and unbalanced stereo audio, as well as digital
audio.
In particular, the VP-81SIDN:

Has a bandwidth of 1.65Gbps per video channel

Can be cascaded with up to four VP-81SIDN devices via the HDMI port to
provide up to 37 Twisted Pair inputs

Supports the SID range of Step-in Commander panels for remote inputs and
remote step-in control

Has a USB power port that can provide power to USB devices, (for example,
the Kramer KW-11T)

Is HDCP compliant

Provides EDID capture – Copies and stores the EDID from a display device
You can control the VP-81SIDN using the front panel buttons, or remotely via:

RS-485 or RS-232 serial commands transmitted by a touch screen system,
PC or other serial controller

Ethernet over a LAN

The Kramer RC-IR3 Infrared Remote Control Transmitter or the
CA35M/IRR-50 infrared remote extension cable transmitter (optional)
