VP-81SIDN - Operating the VP-81SIDN Remotely 27
Figure 12: Step-In Software Main Window
The following table describes the main window features.
# Feature Function
1 Connect/Disconnect
Button Click to connect to or disconnect from the device (see Section
9.1.4 )
2 Selected Input Buttons Click to select an input. The selected input button is highlighted
3 Device 2 Cascaded
Device(s) Inputs of any cascaded devices
4 Current User Label Indicates which user is currently logged in (see Section 9.1.15 )
5 Log In Button Click to log in (see Section 9.1.3 )
6 Inputs Twisted Pair
Buttons Click one of the eight remote Twisted Pair input buttons to select
an input (see
Section 9.1.16 )
7 Local Input Buttons Click one of the two local input buttons to select an input
8 Outputs Buttons Click one of the two output buttons to select an output (see
Section 9.1.17 )
