# Feature Function
12 LOCAL AUDIO
INPUTS DVI Connect to the local DVI audio source
13 HDMI Connect to the local HDMI audio source
14 HDMI OUT Connector Connect to the local HDMI acceptor
15
AUDIO
OUTPUTS
+L –G+R– Connect to the balanced audio acceptor (see Section 6.1 )
16 R Connect to the unbalanced audio acceptor right channel
17 L Connect to the unbalanced audio acceptor left channel
18 S/PDIF Connect to the digital audio acceptor
19 PROG TERM DIP-Switch DIP-Switch 1: Sets the RS-485 bus termination (see Section 8.3 ).
Up = Off, Down = On (Default = On)
DIP-Switch 2: For the use of Kramer service personnel only
20 RS-485 3-way Terminal Block Connect to RS-485 port on a remote controller or another VP-81SIDN.
Connect: G to Ground, A to A, and B to B (see
Section 6.4 )
21 RESET Button Press while power-cycling the device to reset parameters to factory default values
22 REMOTE IR 3.5mm Mini Jack Connect to an external IR receiver unit for controlling the device via an IR remote
controller (see
Section 3.3 )
