VP-1608 - Hex Tables for Audio Input/Output Gain Control 33
11 Hex Tables for Audio Input/Output Gain
Control
Sections 11.1 and 11.2 contain the tables of hex codes for input and output signal
gain control adjustment, respectively.
11.1 Hex Tables for Audio Input Gain Control
Before adjusting the audio inputs gain, instruction 42, the AUDIO PARAMETER
SETTINGS FOR INSTRUCTIONS 22, 24, 25 is sent. This command is sent once,
and the “audio inputs gain adjustment” mode continues until instruction 42
changes to the “audio outputs gain adjustment” mode:
2A 86 80 81
The next table lists the hex values for the audio gain control of the 16 inputs:
