Overview
4
3 Overview
This user manual describes the following products:
Kramer TOOLS VP-200XLT XGA Line Amp / CAT 5 Transmitter,
which accepts one computer graphics input and distributes the signal
to its high-density 15 pin “D” connector output, as well as
transmitting it over UTP cabling (CAT 5 or similar) to its appropriate
receiver, see section 4
Kramer TOOLS VP-200XLTHD XGA Line Amp / CAT 5
Transmitter, which accepts one computer graphics input and
distributes the signal to its high-density 15 pin “D” connector output,
as well as transmitting it over UTP cabling (CAT 5 or similar) to its
appropriate receiver, see section 5
Kramer TOOLS VP-300T 1:2 XGA DA/ CAT 5 Transmitter, which
is a distributor for computer graphics signals, accepting one input
and distributing the signal to its identical 2 outputs, as well as
transmitting it over CAT 5 UTP cable to its appropriate receiver, see
section 6
Kramer VP-5T/VP-5THD 1:4 VGA/UXGA Distributor / CAT 5
Transmitter, which is a distributor for computer graphics signals,
accepting one input, and distributing the signal to its identical 4
outputs, as well as transmitting it over CAT 5 UTP cable to its
appropriate receiver, see section 7
Kramer VP-5R CAT 5 Receiver / 1:5 VGA/UXGA Distributor, which
is a distributor for computer graphics signals, receiving the computer
graphics signal via CAT 5 UTP cable, and distributing the signal to 5
identical 15-pin HD outputs, see section 8
This section describes:
The power connect feature, see section 3.1
Using shielded twisted pair (STP) / unshielded twisted pair (UTP),
see section 3.2
Recommendations for achieving the best performance, see section
3.3
3.1 About the Power Connect Feature
The Power Connect feature applies as long as the cable can carry power. The
distance does not exceed 50m on standard CAT 5 cable, for longer distances,
heavy gauge cable should be used 1 .
1 CAT 5 cable is still suitable for the video/audio transmission, but not for feeding the power at these distances
