Connecting the VP-5T/VP-5THD and the VP-5R

11 Connecting the VP-5T/VP-5THD and the VP-5R

You can use the

VP-5T/VP-5THD 1:4 VGA/UXGA Distributor / CAT 5

Transmitter and the

VP-5R

CAT 5 Receiver / 1:5 VGA/UXGA Distributor to

configure an XGA Line-to-Twisted Pair Transmitter and Receiver system.
To connect the

VP-5T/VP-5THD with the VP-5R, as the example in

Figure 12 illustrates, do the following:

1. On the

VP-5T/VP-5THD , connect the computer graphics source (for

example, a computer) to the INPUT 15-pin HD connector, and connect

up to

4 acceptors (for example, local displays) to the OUTPUT 15-pin

HD connectors 1 to 4.

2. On the

VP-5R, connect up to

5 acceptors (for example, displays) to the

OUTPUT 15-pin HD connectors 1 to 5.

3. Connect the CAT 5 OUT RJ-45 connector on the

VP-5T/VP-5THD to the

CAT 5 LINE IN RJ-45 connector on the

VP-5R, via UTP cabling (with a

range of more than 300ft (more than 100m)), see section 11.1.

4. Connect the power cord

(not illustrated in Figure 12) to the

VP-5T/VP-5THD , and connect the other power cord

to the

VP-5R.

5. On the

VP-5T, if required:

Adjust

the front panel cable ompensation equalization

level

Set the underside ID BIT Control switches

6. On the

VP-5THD, if required:

Set the H SYNC and V SYNC switches

on the underside

7. On the

VP-5R, if required:

Adjust

the front panel LINE INPUT signal level and/or

cable compensation equalization level, and/or OUTPUT

compensation equalization level

Set the V SYNC and H SYNC switches

, on the underside

1 When not all the outputs are required, connect only those that are required and leave the other output(s) unconnected
2 We recommend that you use only the power cord that is supplied with each specific machine
3 Use a screwdriver to carefully rotate the trimmer, adjusting the appropriate level
4 By default, both switches are set down (for negative V SYNC and H SYNC polarity)
