Technical Specifications
25
Table 13: Technical Specifications of the VP-300T (with 30m CAT 5 cable)
INPUTS:
1 XGA on an 15-pin HD connector
OUTPUTS:
2 XGA on 15-pin HD connectors
1 RJ-45 connector
MAX. OUTPUT LEVEL
1
: 1.9Vpp (XGA), 1.3Vpp (CAT 5)
BANDWIDTH (-3dB):
439MHz (XGA), 152MHz (CAT 5)
DIFF. GAIN
1
:
0.05% (XGA), 3.1% (CAT 5)
DIFF. PHASE
1
:
0.05Deg (XGA), 0.4Deg (CAT 5)
K-FACTOR
1
:
<0.05% (XGA and CAT 5)
S/N RATIO
1
:
76dB (XGA), 71dB (CAT 5)
CONTROLS
1
:
LEVEL: –8.9dB to 3.9dB (CAT 5)
EQ.: 0 to 30dB (CAT 5)
COUPLING
1
:
DC (XGA), AC (CAT 5)
POWER SOURCE:
12 VDC 130mA
DIMENSIONS:
12cm x 7.5cm x 2.5cm (4.7" x 2.95" x 0.98”) W, D, H
WEIGHT:
0.3kg (0.67lb) approx.
ACCESSORIES:
Power supply
Table 14: Technical Specifications of the VP-5T/VP-5THD (with 60m CAT 5 cable)
INPUTS:
1 XGA on an 15-pin HD connector
OUTPUTS:
4 XGA on 15-pin HD connectors
1 RJ-45 connector
MAX. OUTPUT LEVEL
2
: 1.7Vpp (XGA), 1.7Vpp (CAT 5)
BANDWIDTH (-3dB):
445MHz (XGA), 154MHz (CAT 5)
RESOLUTION:
Up to UXGA, up to 1080p
3
DIFF. GAIN
2
:
0.8% (XGA), 3.2% (CAT 5)
DIFF. PHASE
2
:
0.08Deg (XGA), 0.06Deg (CAT 5)
K-FACTOR
2
:
0.1% (XGA), <0.05% (CAT 5)
S/N RATIO
2
:
76dB (XGA), 73dB (CAT 5)
CONTROLS
2
:
LEVEL: –7.4dB to 3.5dB (CAT 5)
EQ.: 0 to 37.8dB @50MHz (CAT 5)
COUPLING
2
:
DC (XGA), AC (CAT 5)
POWER SOURCE:
230 VAC, 50/60 Hz. (115VAC, U.S.A.) 13VA
DIMENSIONS:
22cm x 18cm x 4.5cm (8.7” x 7” x 1.7”) W, D, H (half 19”, 1U)
WEIGHT:
1.2kg (2.6 lbs) approx.
ACCESSORIES:
Power cord
1 For the VP-300T to TP-120 SETUP
2 For the VP-5T to TP-120 SETUP
3 The HD resolutions apply to the HD version of the machine
