Kramer Electronics VP-300T - Manual (Page 29)

KRAMER: SIMPLE CREATIVE TECHNOLOGY
Technical Specifications
26
Table 15: Technical Specifications of the VP-5R (with 30m CAT 5 cable)
INPUTS: 1 RJ-45 connector
OUTPUTS: 5 XGA on 15-pin HD connectors
MAX. OUTPUT LEVEL 1 : 1.4Vpp
BANDWIDTH (-3dB): 150MHz
DIFF. GAIN 1 : 3.4%
DIFF. PHASE 1 : 0.05Deg
K-FACTOR 1 : <0.05%
S/N RATIO 1 : 74dB
CONTROLS 1 : LEVEL: –8.2dB to 4.3dB
LINE EQ.: 0 to 30dB; OUT EQ.: 0 to 8.6dB
COUPLING 1 : AC
POWER SOURCE: 230V AC, 50/60 Hz. (115V AC, U.S.A.) 9.2VA
DIMENSIONS: 22cm x 18cm x 4.5cm (8.7” x 7” x 1.7”) W, D, H (half 19”, 1U)
WEIGHT: 1.2kg (2.6 lbs) approx.
ACCESSORIES: Power cord
1 For the VP-5R to WP-110 SETUP
