SLG−Z−...
Festo SLG−Z−... 0512a English
29
11
Technical specifications
Type
SLG−...
8−...−Z..
12−...−Z..
18−...−Z..
Mounting position
As desired, (e.g. on fastening rail type SLG−S−...)
Medium
Filtered (min. 40
ìm) lubricated or non−lubricated
compressed air
Cushioning type
Hydraulic cushioning (with SLG−...−Z−YSRG−...)
elastic cushioning (with SLG−...−ZP−...)
Operating pressure
Min. 1 bar ... max. 8 bar
Connections
M3
Max. cushioning energy per stroke
Ĉ SLG−...−Z−P−...
Ĉ SLG−...−Z−YSRG−...
1 800 J
18 000 J
10 800 J
54 000 J
Max. permitted impact force
Ĉ SLG−...−Z−P−...
Ĉ SLG−...−Z−YSRG−...
100 N
320 N
450 N
600 N
Max. actuation frequency
1 Hz
Max. impact speed
1 m/s
1.5 m/s
Extending/retracting time
*)
0.1 s
0.15 s
Permitted temperature range
− 10 ... max. + 60 °C
Materials
Housing:
Al (anodized)
Toothed rod:
POM
Pinion:
St
Screws, sliding block:
St
Seals:
PU
Rubber buffer:
NBR
Weight (SLG−...−Z..)
33.5 g
33.5 g
75 g
Fig. 28
*)
At 6 bar and T = 20 °C
