6G-SDI Extender Over UTP
Page 16
3.7.
SDI Input Connection
SDI, Input BNC Connector (Transmitter)
Input
Modes
SDI A
SDI B
SDI C
SDI D
Single 6G-
SDI
Link A
---
---
---
Single 3G-
SDI
Link A
---
---
---
Dual 3G-
SDI
Link A
Link B
---
---
Single
HD-SDI
Link A
---
---
---
Dual HD-
SDI
Link A
Link B
---
---
Quad HD-
SDI
Link A
Link B
Link C
Link D
Table 6
– SDI Input Connections Matrix
3.8.
SDI Output Connection
SDI, Input BNC Connector (Receiver)
Input
Modes
SDI A
SDI B
SDI C
SDI D
Single 6G-
SDI
Link A
---
Link A’
---
Single 3G-
SDI
Link A
---
Link A’
---
Dual 3G-
SDI
Link A
Link B
Link A’
Link B’
Single
HD-SDI
Link A
---
Link A’
---
Dual HD-
SDI
Link A
Link B
Link A’
Link B’
Quad HD-
SDI
Link A
Link B
Link C
Link D
Table 7
– SDI Output Connections Matrix
Notes:
Link A’ and Link B’ are redundant outputs of Link A & B.
