© MuxLab Inc. LongReach 16 Active CCTV Receiver Hub Installation Guide
Page 5
2.
Technical Specifications
Environment CCTV equipment for security and surveillance. RS-343 (RS-170) NTSC, PAL
Devices CCTV cameras, DVR, IP camera encoders, monitors, switchers, multiplexers
and other CCTV equipment.
Transmission Transparent to the user
Bandwidth DC to 4.5 MHz.
Input 1.5 Vp-p max, 100Ω, balanced
Output 1.1 Vp-p, ± 1 dB, 75Ω, unbalanced
Insertion Loss -14 dB minimum for luma, -60 dB minimum for chroma.
Determined by Automatic Gain Control.
Return Loss Greater than 15 dB over the frequency range
Common Mode Rejection
Ratio Greater than 40 dB @ 3.85 MHz
Maximum Distance via Cat
5/6 UTP* NTSC: Camera to Hub: 4,000 ft (1,219m); Hub to DVR:500 ft (152m).
Total:4,500’ (1,371m)
PAL: Camera to Hub: 3,000 ft (914m); Hub to DVR: 350 ft (107m). Total:
3,350’ (1,021m).
*Longer distances may be achieved when connected directly to a CCTV
monitor.
Automatic Gain Control (AGC) Automatic Gain Control for sharpness and luminosity.
LED Indicators Power: One (1) green LED. Video Sync: Sixteen (16) green LEDs.
Cable – UTP 24 gauge or lower solid copper twisted pair wire impedance: 100 ohms at 1
MHz. Maximum capacitance: 20 pf/foot. Attenuation: 6.6 dB/1000 ft at 1
MHz
Cable – BNC Impedance: 75 ohms at 1 MHz (RG59/U or RG6).
Connectors*
*reverse polarity sensitive.
Video In from cameras: Sixteen (16) 2-pole screw terminals
Video Out to DVR: Sixteen (16) 2-pole screw terminals or sixteen (16) BNC-F
Ground: One (1) chassis ground lug
Compatible Baluns 500000, 500009, 500021, 500022, 500023
Power Consumption – Max. 40W RMS max. @ 24VAC RMS typical (floating; +15%, -10%)
Power Transformer (Included) North America: 110V/24VAC/60VA. Europe: 220-240/24VAC/70VA
Video Ground Loop Isolation ± 50V max permanent voltage. ±100V max surge for 3 seconds
Fuse Rating 3A
Temperature Operating: 0° to 40°C. Storage:-20° to 85°C. Humidity: up to 95% non-cond.
Enclosure Black
Mounting Rack mount (factory default). Removable brackets for wall mount or desktop
installation. Rubber stand-offs included for desktop installation.
Dimensions 19” x 8.6” x 1.75” (48.3 x 21.7 x 4.4 cm)
Weight 4.4 lbs (2 kg)
Regulatory FCC and CE
Warranty 1 year
Order Information 500120 LongReach 16 Active CCTV Hub, UTP/UTP, 110V/24VAC
500121 LongReach 16 Active CCTV Hub, UTP/UTP, 220-240V/24VAC
500122 LongReach 16 Active CCTV Hub, UTP/Coax, 110V/24VAC
500123 LongReach 16 Active CCTV Hub, UTP/Coax, 220-240V/24VAC
