1/4-20 Tapped Hole Thru
CL
CL
1 3/4"
TOP PLATE MODIFICATION
HANDLE ASSEMBLY MODIFICATION
REQUIRED PART MODIFICATIONS
1/4-20 Tapped Hole Thru
3 3/16"
Required Modifications
DO NOT SCALE DRAWING
950 Retrofit Inst
SHEET 2 OF 2
2/22/11 BAB
UNLESS OTHERWISE SPECIFIED:
SCALE: 1:3 WEIGHT: 1.425
REV DWG. NO.
A
SIZE
TITLE:
NAME DATE
Q.A.
MFG APPR.
ENG APPR.
CHECKED
DRAWN
FINISH
MATERIAL
QUANTITY
DIMENSIONS ARE IN INCHES
TOLERANCES:
FRACTIONAL ±.015
ONE PLACE DECIMAL ±.015
TWO PLACE DECIMAL ±.010
THREE PLACE DECIMAL ±.005
ANGULAR ±1°
APPLICATION
USED ON NEXT ASSY
